Cable Termination Kit 3PKNTp-10-35/50(B) 66281 KVT

• Designed for terminating 3-core cables: • with cross-linked polyethylene insulation and copper wire screen • armored or non-armored • for voltages of 6 and 10 kV • Complies with GOST 34839-2022 requirements • Included in the Ministry of Industry and Trade register • Types of cables to be mounted: (A)PvP, (A)PvV, (A)PvBP, (A)PvBV, (A)PvPu, (A)PvPpg, (A)PvPupg, (A)PvP2g, (A)PvPup2g • The presence of electric field stress equalization tubes ensures the reliability of the operation of the sleeves due to the uniform distribution of electric field stress at the cross-sections of the semiconductor screens of the cable cores • The material of the insulating tube and insulators is brick-red in color and resistant to tracking, ultraviolet radiation, and climatic conditions • Outdoor mounting sleeves are equipped with anti-tracking core insulators that increase the leakage current paths and create dry zones on the surface of the sleeve • Thermoplastic glue applied to the inner surface of the heat-shrinkable glove and anti-tracking tubes ensures the complete tightness of the sleeve after installation • The grounding wire is formed directly from the wire screen of the cable and is terminated with a crimp terminal • The standard kit of the sleeve includes a constant pressure spring for connecting the grounding wire to the armor tapes • When installing the grounding unit on a cable with armor made of steel or aluminum wires, it is necessary to additionally use the "KMPB grounding kit" corresponding to the selected sleeve. • The sleeve kit is universal and allows the use of both crimp cable terminals and bolt terminals • High quality of components and composite materials used • Installation tools: PG (KVT) propane torch, NMB-6 (KVT) bolt terminal and connector removal kit, insulation and semiconductor screen removal tools • All polymer compositions used for the production of KVT heat-shrinkable components are halogen-free (HF=Halogen Free) • Manufactured according to TU 3599-005-97284872-2015
