Cable termination 4PKTp-1-16/25(B) ng-LS 70516 KVT

• Designed for terminating 4-core cables: • with plastic insulation (PVC/PE) • with or without armor (the designation for cable sleeves with armor includes "(b)") • for voltage up to 1 kV • Complies with GOST 34839-2022 requirements • Types of cables for installation: (A)VVGng-LS, NYMng-LS, (A)PvVGng-LS, (A)VBbShvng-LS, (A)VBVng-LS, AVVBng-LS, (A)AVVGng-LS, (A)PvBbShvng-LS, (A)PvBbShpng-LS • Thermoplastic adhesive applied to the inner surface of the glove and end sleeves ensures complete sealing of the sleeve after installation • For armored cables, a non-soldered grounding system is used. The basic configuration includes a constant pressure roller spring used to fasten the grounding wire to the armor tapes • When installing the grounding unit on a cable with armor made of steel or aluminum wires, it is necessary to additionally use the "KMPB grounding kit" corresponding to the selected sleeve. • Materials used for the heat-shrinkable components of the sleeve are resistant to ultraviolet radiation and favorable climatic conditions • The sleeve kit is universal and allows the use of both crimp cable lugs and bolt lugs • Installation tools: propane torch PG (KVT), set for removing bolt lug heads and NMB-6 connectors (KVT) • Manufactured according to TU 3599-006-97284872-2006
