Cable termination outdoor 10kV 10KNTpN-3x(70-120) with bolted lugs Neva-Trans Komplekt 22020121

Cable termination kit, mark 10KNTpN-3x(70-120) with bolt terminals for outdoor installation, designed for terminating 3-core power cables with cross-sections of 70, 95, 120 mm² with paper-impregnated insulation, armored or unarmored, for voltages up to 10 kV inclusive. Installed outdoors. Operates at ambient temperatures from -50°C to +50°C and relative humidity up to 98%. Complies with GOST 34839-2022 and TU 3599-012-31930690-2016 requirements. Has passed a series of independent tests in accredited laboratories, on the basis of which certificates of conformity to GOST, TU, fire, and environmental safety requirements were issued. Mounted on the cable stripping by heat-shrinking modified polymer parts using a gas torch or high-temperature heat gun. Universal bolt terminals with breakaway heads included in the cable kit are suitable for both aluminum and copper conductor cables. The combined grounding kit provides for connecting the grounding wire to the metal cable sheath using a constant pressure roller spring and contact file, and to the armor tapes by soldering. Possesses the required level of tracking resistance, resistance to ultraviolet radiation, and exposure to climatic factors. Combines ease of installation and high operational reliability. Service life - at least 30 years.
