Cable joint 3PST-10-70/120 ng-LS 77346 KVT

• Designed for connecting 3-core cables: • with cross-linked polyethylene insulation and copper wire screen • with steel tape armor or without armor • for voltage 6 and 10 kV • Complies with GOST 34839-2022 requirements • Included in the Ministry of Industry and Trade register • Types of cables to be installed: (A)PvP, (A)PvV, (A)PvBP, (A)PvBV, (A)PvPu, (A)PvPg, (A)PvPug, (A)PvP2g, (A)PvPu2g, (A)PvBVng(A,V)-LS, (A)PvVng(A,V)-LS • The presence of electric field stress relief tubes ensures the reliability of high-voltage terminations, providing uniform electric field distribution in the semiconductor screen cut area • The use of thick-walled sleeves made of high dielectric strength material ensures full restoration of the cable core insulation • Cable screens are restored using aluminum shielding tape and jumpers formed from the cable core screens • For armored cables, the termination is equipped with an additional flat jumper wire and constant pressure springs • Thermoplastic adhesive applied to the inner surface of the protective sleeve ensures complete sealing of the termination after installation • Bolt connectors are wrapped with a special sealant that fills voids and irregularities at the bolt shear points and also possesses electric field stress relief properties • The termination kit is universal and allows the use of both crimp sleeves and bolt connectors • High quality of components and composite materials used • When installing the grounding unit on a cable with steel or aluminum wire armor, it is necessary to additionally use the "KMPB Grounding Kit" corresponding to the selected termination • For cables with copper tape screen, it is necessary to additionally use "KMLE Grounding Kits" • Installation tools: propane torch PG (KVT), NMB-6 (KVT) kit for shearing bolt head ends and connectors, tools for stripping insulation and semiconductor screen • Manufactured according to TU 3599-005-97284872-2015
