IEK
Coupling ПСттбэ 4x35/50 s/g soldering PVC/XLPE insulation 1kV IEK UZM-XLBS1-VN4-3550SP
SKU: UZM-XLBS1-VN4-3550SP
ETIM: EC000910
140,616 ₽
Get back 1,406 ₽ in points
Order multiple: 40 шт
Analogues by specifications
No description available
Connection accessories (included)
Screw connector with shear-off head
Operating temperature range
-45...+50
For connecting cables with paper and plastic insulation
Yes
Approval for mining industry use
No
Design
Heat shrink
Number of cores
4
Scope of delivery
With heat-shrink tubes
Shrinkage ratio
3:1
Earthing busbar to cable fastening
Soldering
Material
Heat-shrink polymer
Min full shrinkage temperature
120
Cable armour presence
Yes
Halogen-free
Yes
Rated voltage U0/U (Um)
0.6/1 (1.2) kV
Rated voltage from
1 В
Rated conductor cross-section at
50 кв.мм
Rated conductor cross-section from
35...50 кв.мм
Applicable for
Other
Voltage range
0.6/1 kV
With concentric screening
Yes
With threaded connection
Yes
Insulating material type
PVC/XLPE
Connector type
With shear-head bolt
Installation type
Internal and external
Chemically and UV resistant
Yes
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
