IEK
Cable sleeve Ctt(tp)-10 3x35/50 s/g soldering paper insulation IEK UZM-BIS10-VN3-3550SP
SKU: UZM-BIS10-VN3-3550SP
ETIM: EC001169
9,061 ₽
Get back 90 ₽ in points
Analogues by specifications
No description available
Connection accessories (included)
Screw connector with shear-off head
Operating temperature range
-45...+50
For connecting cables with paper and plastic insulation
Yes
Approval for mining industry use
No
Design
Heat shrink
Number of cores
3
Configuration
With heat shrink tubes and glove
Scope of delivery
With heat shrink tubes and glove
Shrinkage ratio
3:1
Earthing busbar to cable fastening
Soldering
Material
Heat-shrink polymer
Min full shrinkage temperature
120
Cable armour presence
Yes
Halogen-free
Yes
Rated voltage U0/U (Um)
6/10 (12) kV
Rated voltage from
10 В
Rated conductor cross-section at
50 кв.мм
Rated conductor cross-section from
35...50 кв.мм
Applicable for
Other
Voltage range
6/10 kV
With concentric screening
No
With threaded connection
Yes
Insulating material type
Paper-impregnated
Connector type
With shear-head bolt
Installation type
Internal and external
Chemically and UV resistant
Yes
