IEK
Cable sleeve Stt(tp) 3x16/25 non-grease soldering paper insulation 1kV IEK UZM-BIS1-VN3-1625XP
SKU: UZM-BIS1-VN3-1625XP
ETIM: EC001169
130,022 ₽
Get back 1,300 ₽ in points
Order multiple: 50 шт
Analogues by specifications
IEK cable sleeves are made of heat-shrinkable materials for power cables up to 1 kV with various types of protective covers, sheaths, and a wide range of conductor cross-sections.
Sst(tp) cable connection sleeves for indoor and outdoor installation are designed for connecting three-core and four-core armored and non-armored cables with paper insulation for voltages up to 1 kV AC and DC. The sleeves are intended for installation on cables of type AAG-1, AASH-1, AAB-1, AAP-1, AABSH-1, AAPSH-1, ASG-1, AASSH-1, ASBSH-1, SG-1, SSH-1, SBSH-1, SB-1, SP-1, SK-1, SBG-1, SPG-1, their analogs, and modifications.
Connection accessories (included)
No
Operating temperature range
-45...+50
For connecting cables with paper and plastic insulation
Yes
Approval for mining industry use
No
Design
Heat shrink
Number of cores
3
Scope of delivery
With heat shrink tubes and glove
Configuration
With heat shrink tubes and glove
Shrinkage ratio
3:1
Earthing busbar to cable fastening
Soldering
Material
Heat-shrink polymer
Min full shrinkage temperature
120
Cable armour presence
Yes
Halogen-free
Yes
Rated voltage U0/U (Um)
0.6/1 (1.2) kV
Rated voltage from
1 В
Rated conductor cross-section at
25 кв.мм
Rated conductor cross-section from
16...25 кв.мм
Applicable for
Other
Voltage range
0.6/1 kV
With concentric screening
No
With threaded connection
No
Insulating material type
Paper-impregnated
Connector type
Without ferrules
Installation type
Internal and external
Chemically and UV resistant
Yes
