NST-SIP NILED 13303381 Die Set

Hexagonal dies type E140, E173 and E215 are used for crimping insulated sleeves and wire terminals of SIP (self-supporting insulated wire) using hydraulic presses. They are designed for hexagonal crimping of MJPB, MJPT, MJPB, MJRP insulated sleeves and CPTA R, CPTA U type terminals. The dies are intended for crimping insulated terminals and sleeves manufactured according to GOST R 70352-2022 and STO PJSC "ROSSETI" requirements. Crimping of connecting crimpable clamps and terminals on a wire should be carried out using a press with hexagonal dies. Dies from the NST-SIP kit are compatible with NST-120 series hydraulic presses. The kit includes 3 dies: E140, E173, E215. Die type - hexagonal. E140 die characteristics Inscribed circle diameter, mm - 14,0 Working part width, mm - 9,0 Minimum crimping force, kN - 30 E173 die characteristics Inscribed circle diameter, mm - 17,3 Working part width, mm - 9,0 Minimum crimping force, kN - 50 E215 die characteristics Inscribed circle diameter, mm - 21,5 Working part width, mm - 9,0 Minimum crimping force, kN - 50
