DKC
Terminal with screw hole and PA insulated flange, 0.5-1.5 sq.mm, M10 (NKI) 2A10P-EE-PA DKC
SKU: 2A10P-EE-PA
ETIM: EC001052
6 ₽
Price list (incl. VAT):
8 ₽
Available August 6
Возврат в течение 7 дней
При отказе от товара надлежащего качества из суммы возврата удерживается стоимость обратной доставки по тарифу СДЭК «дверь-дверь» от вашего адреса до нашего склада плюс 1000 ₽ за обработку возврата. Точную сумму и итог к возврату вы увидите в личном кабинете до отправки заявки.
Привезёте товар на наш склад сами — удержаний нет вовсе, при любой сумме заказа: вернём полную стоимость. Возврат бракованного товара — тоже без каких-либо удержаний.
Полные условия возврата →Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse (Тверь)
Available
|
2100 | шт | August 6 | clarifying |
Select a warehouse to order
Cable lugs are special accessories designed for terminating cables and wires with copper cores with a cross-section from 0.5 to 1.5 mm2 in AC and DC electrical circuits, voltage up to 600 V. Contact part material – M1 copper, insulation material - PA 6.6. A distinctive feature of the lugs is the bell-shaped sleeve (EasyEnter) to facilitate the insertion of multi-strand copper cores without the risk of damage. The inner surface of the contact sleeve has serrations that increase contact density during crimping. Tin plating provides corrosion protection. The flange is insulated. Hardware - M10. Color - red.
| In accordance with DIN | Yes |
| AWG cross-section range to | 16 |
| AWG cross-section area range with | 16 |
| For strain-relieved connections | Yes |
| Protective surface coating | Tin-plated |
| Insulated | Yes |
| Insulation | Polyamide |
| Insulation | EV003881 |
| Maximum current (Imax) | 19 А |
| Material | Copper |
| Metric connecting thread size | 10 |
| Rated cross-section at | 1.5 кв.мм |
| Rated cross-section from | It appears your message contains only ".5". Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. кв.мм |
| Suitable for high temperatures (up to 650°C) | Yes |
| Suitable for round conductors | Yes |
| Suitable for stranded conductors | Yes |
| Suitable for stranded conductors | Yes |
| Suitable for flat conductors | Yes |
| Suitable for solid wires | Yes |
| Suitable for enamelled wires | Yes |
| Glued | Yes |
| Contact pad shape | Ring |
| Insulation colour | Red |
