Terminal with screw hole and insulated PA flange, 0.5-1.5 mm², M4 (NKI) 2A4P-EE-PA DKC

Cable lugs are special accessories designed for terminating cables and wires with copper cores with a cross-section from 0.5 to 1.5 mm2 in AC and DC electrical circuits, voltage up to 600 V. Contact part material – M1 copper, insulation material - PA 6.6. A distinctive feature of the lugs is the bell-shaped ferrule (EasyEnter) to facilitate the insertion of multi-strand copper cores without the risk of damage. The inner surface of the contact sleeve has serrations that increase contact density during crimping. Tin plating provides corrosion protection. The flange is insulated. Fastener - M4. Color - red.
