Terminal with screw hole and insulating flange PA, 4-6 sq.mm, M10 (NKI) 2C10P-EE-PA DKC
SKU: 2C10P-EE-PA
ETIM: EC001052
14 ₽
Price list (incl. VAT):
19 ₽
Available August 3
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
900 | шт | August 3 | August 3 |
Select a warehouse to order
Cable terminals are special accessories designed for terminating cables and wires with copper cores with a cross-section of 4 to 6 mm2 in AC and DC electrical circuits, voltage up to 600 V. Contact part material – copper M1, insulation material - PA 6.6. A distinctive feature of the terminals is the bell-shaped ferrule (EasyEnter) to facilitate the insertion of multi-strand copper conductors without the risk of damage. The internal surface of the contact sleeve has serrations to increase contact density during crimping. Tin plating provides corrosion protection. The flange is insulated. Fastener - M10. Color - yellow.
| In accordance with DIN | Yes |
| AWG cross-section range to | 10 |
| AWG cross-section area range with | 10 |
| For strain-relieved connections | Yes |
| Protective surface coating | Tin-plated |
| Insulated | Yes |
| Insulation | Polyamide |
| Insulation | EV003881 |
| Maximum current (Imax) | 48 А |
| Material | Copper |
| Metric connecting thread size | 10 |
| Rated cross-section at | 6 кв.мм |
| Rated cross-section from | 4 кв.мм |
| Suitable for high temperatures (up to 650°C) | Yes |
| Suitable for round conductors | Yes |
| Suitable for stranded conductors | Yes |
| Suitable for stranded conductors | Yes |
| Suitable for flat conductors | Yes |
| Suitable for solid wires | Yes |
| Suitable for enamelled wires | Yes |
| Glued | Yes |
| Contact pad shape | Ring |
| Insulation colour | Yellow |
