DKC
Terminal with screw hole and PVC insulated flange, double barrel, 4-6 sq.mm, M6 (NKI) 2C6P-DS-PVC DKC
SKU: 2C6P-DS-PVC
ETIM: EC001052
1,900 ₽
Get back 19 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 100 шт
Analogues by specifications
Stock by warehouse
No description available
In accordance with DIN
Yes
AWG cross-section range to
10
AWG cross-section area range with
10
For strain-relieved connections
Yes
Protective surface coating
Tin-plated
Insulated
Yes
Insulation
Polyvinyl chloride (PVC)
Insulation
Polyvinyl chloride (PVC)
Maximum current (Imax)
48 А
Material
Copper
Metric connecting thread size
6
Rated cross-section at
6 кв.мм
Rated cross-section from
4 кв.мм
Suitable for high temperatures (up to 650°C)
Yes
Suitable for round conductors
Yes
Suitable for stranded conductors
Yes
Suitable for stranded conductors
Yes
Suitable for flat conductors
Yes
Suitable for solid wires
Yes
Suitable for enamelled wires
Yes
Glued
Yes
Contact pad shape
Ring
Insulation colour
Yellow
