Insulated Twin Bootlace Ferrule NShVI(2) 1.0-10 79465 KVT

• For installation of twin wires of the same cross-section • Designed for terminating flexible multi-strand copper conductors using the crimping method. They transform the ends of multi-strand wires into solid pins • A modern alternative to the mandatory tinning of multi-strand conductor ends when connecting to terminals • Dimensions of the insulated sleeves and NShVI(2) ferrule bushings are designed for the installation and connection of two conductors • In high-density installation conditions, double ferrule terminals are the only possible contact connection for two conductors • Connector material: M1 grade copper • Connector coating: electrolytic tinning • Insulation material: polypropylene. Halogen-free • Insulation heat resistance: 105 °C • The color of the insulating sleeves is made in accordance with the color coding of DIN 46228, part 4 • Single and double ferrule terminals from "KVT" are presented in the same color scheme as the DIN standard, which facilitates their size-based identification • The conical shape of the sleeve, "Easy Entry" type, facilitates the insertion of the multi-strand wire into the copper ferrule • Crimping the wire over the copper ferrule
