Patch panel with cable organizers 19inch 2U 48 ports UTP RJ-45 CAT 6 PRO Rexant 02-0232

Patch panel – one of the components of a structured cabling system (SCS). It is a panel with multiple connection connectors located on the front side. On the rear side, the contacts are intended for fixed connection with cables. REXANT PRO patch panel is made of high-quality durable materials and belongs to passive network equipment. Technical characteristics: Connectable conductors: single-core 22-26 AWG Number of connections: at least 750 cycles Connector retention force: 50N/1 min Materials: Housing: 1.6 mm steel Printed circuit board (PCB): double-sided glass fiber reinforced plastic (FR-4) 1.6 mm Housing: impact-resistant ABS plastic, UL-94V-0 IDC module housing: polycarbonate (PC), UL-94V-0 Connectors: ABS plastic, UL-94V-0, contacts – phosphor bronze with 1.27 μm gold plating over 2.54 μm nickel IDC contacts: phosphor bronze with 2.54 μm tin alloy coating Organizer material: 1.6 mm steel
