PRO-Screen operator panel is a human-machine interface device designed to create monitoring and control systems for technological processes. The device is configured and programmed using PRO-Screen master software. PRO-Screen operator panels are used in any industry based on programmable logic controllers, automated control systems, and industrial automation devices. They can work together with devices from any manufacturer.
Web browser
No
Weight
2.25 кг
Printout possible
Yes
Wall/surface mounting possible
No
Busbar mounting possible
No
Capability to load additional software components
Yes
Depth
35.6 мм
Mounting installation depth
28 мм
Screen diagonal
15.6 дюйм
Display design
Touch display (TFT)
Number of HW wireless interfaces
1
Number of HW USB interfaces
2
Number of industrial Ethernet HW interfaces
1
Number of HW serial RS-232 interfaces
1
Number of HW serial RS-422 interfaces
2
Number of HW serial RS-485 interfaces
2
Number of vertical pixels
1 080
Number of horizontal pixels
1 920
Number of function buttons, programmable
0
Number of display colours
16 700 000
Number of online languages
7
Maximum power consumption
18 Вт
Maximum power consumption
750 мА
Mounting height
256 мм
DC supply voltage to
28 В
DC supply voltage from
18...28 В
RAM
0.512 Гб
ASI protocol support
No
CAN protocol support
No
DeviceNet protocol support
No
Ethernet / IP protocol support
No
KNX protocol support
No
LON protocol support
No
MODBUS protocol support
Yes
PROFIBUS protocol support
No
TCP/IP protocol support
Yes
Protocol support for other system buses
Yes
Suitable for distribution board
Yes
Usable project memory / user memory
512 000 кБайт
Pre-installed operating system
Linux operating system
Programmable
Yes
Operating temperature
50 град.C
Operating temperature from
0...50 град.C
Supply voltage current type
DC (direct)
With message indication
Yes
With touchscreen
Yes
With messaging system (including buffer and acknowledgement)
Yes
With colour display
Yes
Touch
Resistive sensor
SD memory card slot
No
With audible indication
Yes
Ingress protection (IP) of front side
IP65
Front protection rating (NEMA)
4X
GPU clock frequency
1 000 МГц
Processor clock frequency
1 000 МГц
Frontal height
256 мм
Frontal width
394 мм
Real-time clock (RTC)
Yes
Number of greyscale levels
256
Installation width
378 мм
Brightness
250 кд/кв.м
