0-1 switch with latch (1NO+1NC) EMAS CP102S20

EMAS switches are used to sequentially disconnect and connect low-voltage electrical circuits. For example, two-way switches are designed for convenient lighting control in various rooms, staircases, and corridors. Such electrical switches are mounted between floors or near doors of rooms with multiple entrances. Maximum functionality Easy installation Block contacts are equipped with a flame-retardant V0 PA6 housing Ability to connect an illumination block contact Plastic parts are made of polycarbonate Convenient and safe cable connection Minimal heating, maximum service life Any installation position possible Mechanical life 500,000 operations (minimum value) Electrical life 100,000 operations (minimum value) Operating temperature -5C / +40 C Protection IP IP65 Operating frequency 1200/3000 operations per hour Rated voltage, Ue 240V AC Rated current, Ie 4A Rated insulation voltage, Ui 300V Rated impulse voltage, Uimp 2.5 kB Rated insulation resistance not less than 10 MOhm (at 500V DC) Contact material AgNI Dielectric strength Between housing and contact -2000V AC: open contact -1500V AC Cross-section of connecting cable 1.5 -2.5 sq.mm Standard UL 508, TS EN 60947-5-1, VDE0660
