Emergency switch 3p+neutral two-position (0-1) 32A EMAS PSA032AK941E

PS series cam switches are mechanical devices with no power consumption of their own and are intended for installation as switching devices in electrical circuits. Also, PS series switches can be used as main switches or group switches for controlling drives based on single- or three-phase motors, switching with a required control circuit program, signaling, or in measuring circuits. Used in AC electrical circuits with voltage from 220 to 400 V. High precision Variety of modifications for a wide range of applications Long service life Compact bakelite housing Wide range of switches Ergonomic handle Mechanical life: 100,000 operations (minimum value) Electrical life: 50,000 operations (minimum value) Operating temperature: -5C / +40 C IP Protection: IP54 and IP56 (Front side) Maximum breaking capacity: 6 kA Operating voltage: 220V - 400V Operating current: 10A - 120A Dielectric strength: 1890V AC (for 1 minute) Insulation resistance: 10 MOhm (at 500V DC) Operating frequency: 50 Hz Standard: TS EN 60947-3
