Inductive proximity switch 18mm IP67 wire connection EMAS SIM18FM1RC2

Inductive sensor (PNP-NC), cable 2m*3 (sensing distance 5mm, 800 Hz), flush mounting, 10-30V DC, IP67 Product - Inductive sensor Inductive sensor series - SIM Housing material - Metal Type - Flat Output/contact type - PNP-NC Sensing distance - 5 mm Connection type - 2 m wired Connection / Nominal size - M18 Mounting method - Flush Operating voltage 10-30 V DC Dielectric voltage (Ui) 1500 V AC Impulse voltage resistance (Uimp) 75 V DC Operating temperature -25°C…+70°C Pollution degree 3 Protection class IP67 Hysteresis <15% Sr (operating range) Number of contacts 1 Repeatability <0.1 Sr Switching frequency 800 Hz Reverse polarity protection VAR Short circuit protection VAR Max. load current Output scanning 200 mA Temperature drift <0.1 Sr First delay before opening no more than 100 ms No-load current <15 mA Leakage current no more than 0.5 mA Min. load current <1 mA Voltage drop <2 V Fluctuation (voltage) <10% EMC 61000-4-3 3 V/m -- 61000-4-6 3 Rated short-circuit current 100A Application category - Rated operating current DC 13 - 200 mA. Detection face PBT Cable number and cross-section 3 x 0.34 mm² High switching speed Resistant to abrasion and wear. Models with cable and connector. Short circuit and overload protection. Reverse polarity protection.
