EMAS
Inductive non-contact switch 18mm IP67 wire connection EMAS SIM18NM1RC2
SKU: SIM18NM1RC2
ETIM: EC002714
4,887 ₽
Get back 48 ₽ in points
Analogues by specifications
No description available
Sensor height
62 мм
Sensor diameter
18 мм
Switching output design
PNP/NC
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of safe semiconductor outputs
0
Number of safe semiconductor outputs with signaling function
0
Number of safety outputs with contact
0
Number of safe outputs with signalling function contact
0
Housing construction
Threaded cylinder
Maximum output current at protected output
200 мА
Housing material
Metal
Mechanical installation requirement for sensor
Flush
Supply voltage to
30 В
Supply voltage from
10 В
Suitable for security systems
Yes
Housing coating
Chrome plating
Immunity to magnetic fields
Resistance to DC and AC magnetic fields
Operating distance
8 мм
Current type
Direct current (DC)
Cascadable
No
With monitoring function for connected devices
No
Actuation method
Magnetic
Connection type
Cable
Resistance to load
Yes
Switching frequency
400 Гц
Sensor width
24 мм
