Cam switch in enclosure standard handle 40A scheme 53 IEK MI-CS20-040-053

SKU: MI-CS20-040-053

ETIM: EC002611

4327 ₽

Price list (incl. VAT): 4917 ₽

Available August 20

Order multiple: 20

Availability

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	181	шт	August 20	August 20

Select a warehouse to order

Description Specifications Reviews

Design as auxiliary/maintenance switch	Yes
Version as main switch	Yes
Number of auxiliary NO contacts	0
Number of auxiliary break contacts	0
Number of switch positions	3
Number of poles	3
Complete device in housing	Yes
Design	Surface-mounted device
Maximum rated operational voltage Ue AC	690 В
Mech. endurance	0.3
Modular design	No
Circuit diagram number	53
Rated impulse withstand voltage	4
Rated power at AC-23 230V	1
Rated power at AC-23 400 V	1
Rated power at AC-3 230 V	9
Rated power at AC-3 400 V	1
Rated AC operating voltage of contacts	230; 400; 690
Nominal operating voltage of DC contacts	24; 48; 110; 220
Rated operational current Ie at AC-2 230 V	24
Rated operational current Ie at AC-2 400 V	24
Rated operational current Ie at AC-21 AC-22 230 V	40
Rated operating current Ie at AC-21 AC-22 400 V	40
Rated operational current Ie at AC-23 230 V	35
Rated operating current Ie at AC-23 400V	35
Rated operating current Ie at AC-3 230 V	12
Rated operating current Ie at AC-3 400V	12
Rated thermal current Ith	40
Rated conditional short-circuit current Icn	10
Rated connection capacity	10
Rated voltage	690 В
Rated insulation voltage Ui	690 В
Rated DC voltage from	24; 48; 110; 220 В
Rated continuous current Iu	40.0 А
Position designation	1-0-2
Suitable for front panel mounting	No
Suitable for base mounting	No
Suitable for intermediate mounting	Yes
Suitable for distribution board	No
Front panel size	Other
With control unit	No
With return to zero position	No
With zero position	Yes
Stranded flexible conductor cross-section from	4…10 кв.мм
Ingress protection (IP) of front side	IP65
Ingress protection (IP) in enclosure	IP65
Ingress protection (IP) - contact side	IP00
IP protection rating	IP65
Operating temperature from	-5…40 град.C
Switch type	Multi-step selector switch
Switch type	Multi-step selector switch
Product/component type	Cam switch
Design type	In the housing
Main electrical circuit connection type	Screw connection
Control element type	Short rotary handle (narrow grip)
Fuse current qG	80
Switch position latching	Yes
Switching function	Multi-step selector switch
Colour	Black
Color	Black
Electrical endurance	0.0015
