IEK
Key switch 2 positions 1NO+1NC black MASTER IEK MI-SW60-11Y-3-34-2-K02
SKU: MI-SW60-11Y-3-34-2-K02
ETIM: EC001028
6,503 ₽
Get back 65 ₽ in points
Order multiple: 10 шт
Analogues by specifications
Stock by warehouse
Designed for rapid control of contactors (magnetic starters) and automation relays in AC circuits with a frequency of 50 Hz and voltage up to 660 V, or DC circuits with voltage up to 440 V. Compliant with TR CU 004/2011 and GOST IEC 60947-5-1 requirements.
Height
29.0 мм
Height
29.0 мм
Depth
89.0 мм
Hole diameter
22.0 мм
Hole diameter
22.0 мм
Electric shock protection class
Please provide the text you would like me to translate. I am ready to translate your product data from Russian to English following all your specified rules.
Number of auxiliary NO contacts
1
Number of auxiliary break contacts
1
Number of switch positions
2
Number of poles
2
Complete device in housing
No
Design
Built-in device
Maximum rated operational voltage Ue AC
660 В
Mech. endurance
3
Rated AC operating voltage of contacts
48; 120; 230; 400; 660
Nominal operating voltage of DC contacts
24; 48; 110; 220; 440
Rated operating current Ie at AC-15 400 V
4.5
Rated thermal current Ith
10
Rated connection capacity
2.5
Rated insulation voltage Ui
690 В
Rated DC voltage from
440 В
Rated operational current Ie at AC-15, 230V
7.5 А
Rated continuous current Iu
10.0 А
Suitable for front panel mounting
Yes
Suitable for base mounting
No
Suitable for intermediate mounting
Yes
Suitable for distribution board
No
With return to zero position
No
With zero position
Yes
Stranded flexible conductor cross-section from
2.5 кв.мм
Ingress protection (IP) of front side
IP65
Operating temperature from
-25…55 град.C
Switch type
ON/OFF switch
Switch type
ON/OFF switch
Product/component type
Cam switch
Control element type
Short rotary handle (narrow grip)
Fuse current qG
10
Switch position latching
Yes
Switching function
ON/OFF switch
Colour
Black
Color
Black
Width
41.5 мм
Electrical endurance
1
0
★★★★★
