Световые Технологии
LED luminaire PIXEL LED 595 3L D60 W 4000K recessed ST 1094000150 Svetovye tekhnologii
SKU: 1094000150
ETIM: EC002892
16,631 ₽
Get back 166 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
LED luminaires for office, administrative, educational, and other public institutions. The optical system consists of lens optics covered by a mask. Thus, even at small viewing angles, light sources are hidden from the observer, and the generalized discomfort factor due to the use of two types of lenses D60 and D90 can vary from 13 to 19 (13<UGR<19). Upon request, modifications can be created for various types of ceiling systems and edges, as well as changes in dimensions, body color, and color temperature. They are installed in suspended ceilings of the Armstrong type with a load-bearing T-profile shelf width of 15 and 24 mm, and modifications for clip-in type ceilings are also possible. All-metal welded body made of sheet steel, coated with white powder paint. The driver is integrated into the luminaire.
Without dimming
Yes
Supplied with lamp
Yes
Outer diameter
0 mm
Built-in length
575 mm
Built-in height/depth
32 mm
Height/depth
32 mm
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
GPRS dimming
No
LineSwitch dimming
No
RF dimming
No
Zigbee dimming
No
Dimming depending on control mechanism
No
Voltage modulation dimming
No
Push-button dimming
No
Trailing-edge phase dimming
No
Leading-edge phase-cut dimming
No
Length
596 mm
Colour rendering index
80-89 (class 1B)
Grille design
Other
Electric shock protection class
I
Built-in luminaire energy efficiency class
A++, A+, A (LED)
Power factor
0.9
Maximum power
26 W
Housing material
Steel
Diffuser/lampshade material
Without cover
Mounting diameter
0 mm
Rated voltage up to
230 V
Rated voltage from
230...230 V
Rated luminous flux
3200 lm
Rated current from
113...113 mA
Ballast included
Yes
Suitable for ceiling fastening
No
Suitable for lamp power to
26 W
Suitable for lamp power from
26...26 W
Suitable for wall mounting
No
Suitable for continuous light lines
No
Suitable for surface mounting
No
Suitable for suspended mounting
No
Suitable for number of light sources
1
Suitable for emergency lighting
No
Dimming potentiometer (built-in)
No
Designed for flush mounting
Yes
Programmable dimming
No
Fire protection "d"
No
Light distributor
No (without)
DSI dimming
No
Current type
AC/DC
With motion sensor
No
With light sensor
No
With protective grille/mesh/screen
No
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
2.5 mm²
Sinusoidal dimming
No
Manufacturer's proprietary dimming system
No
Special application
Domestic (interior) lighting
IP protection rating
IP40
Ambient temperature up to
35 °C
Ambient temperature from
5...35 °C
Lamp type
LED non-replaceable
Light beam angle
Wide beam 41-80°
Impact resistance
IK02
Control device
LED driver (LED power supply)
Housing color
White
Light color
White
Color temperature at
4000 K
Colour temperature from
4000...4000 K
Lamp base (holder)
No (without)
Width
596 mm
Installation width
575 mm
Luminaire efficiency
123 lm/W
