ONI (Группа IEK)
ПЛК 430 Модуль ЦПУ 4 DI 12 UI (0-10 В/DI) 8 RO 2 AO (1 шт 0-10 В и 1 шт 0-20 мА) 24В DC с Ethernet портом с экраном ONI PLC-430-CPU-16U10U-1DC-00
SKU: PLC-430-CPU-16U10U-1DC-00
ETIM: EC000236
85776 ₽
Available August 18
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Смоленск | |
|---|---|---|---|---|---|
|
Склад производителя
Available
|
30 | шт | August 18 | August 18 |
Select a warehouse to order
Модуль ЦПУ ПЛК 430 ONI с возможностью расширения количества каналов ввода-вывода и коммуникаций с помощью модулей расширения. С интегрированным полнофункциональным экраном. 16 дискретных входов, 4 из которых можно использовать как аналоговые 0-20мА, 8 как аналоговые 0-10В и 4 как высокоскоростные счетчики до 60кГц, 4 релейными выходами и 2 аналоговыми выходами 0-20мА/0-10В. Архивация данных процесса при использовании стандартной SD карты. Интегрированы 2 интерфейса RS485, 1 интерфейс RS232 и 1 интерфейс Ethernet с поддержкой Modbus TCP/RTU/ASCII и MQTT протоколов. Напряжение питания 24В DC.
| Rack mounting possible | No |
| Wall/surface mounting possible | Yes |
| Busbar mounting possible | Yes |
| Front mounting possible | No |
| Program memory expansion possible | No |
| Height | 90 мм |
| Height | 90 мм |
| Depth | 58 мм |
| Additional equipment (Ex ia) | No |
| Additional equipment (Ex ib) | No |
| Design | Modular |
| Gas explosion protection category (EU ATEX directives) | No (without) |
| Dust explosion protection category (EU ATEX Directive) | No (without) |
| Number of industrial Ethernet HW interfaces | 1 |
| Number of HW serial RS-232 interfaces | 1 |
| Number of HW serial RS-485 interfaces | 2 |
| Number of analog inputs | 12 шт. |
| Number of analogue outputs | 2 шт. |
| Number of relay outputs | 8 |
| Number of digital inputs | 12 шт. |
| Number of digital outputs | 8 шт. |
| Component, system accessory | No |
| Maximum number of timers | 0 |
| Maximum number of addressable analogue inputs/outputs | 104 |
| Maximum number of addressable digital inputs/outputs | 280 |
| AC supply voltage 50Hz from | - В |
| DC supply voltage to | 28.8 В |
| DC supply voltage from | 20.4 В |
| Memory capacity | 8192 Кб |
| AS-Interface Safety at Work protocol support | No |
| ASI protocol support | No |
| CAN protocol support | No |
| Data Highway protocol support | No |
| DeviceNet protocol support | No |
| DeviceNet Safety protocol support | No |
| Ethernet / IP protocol support | Yes |
| Foundation Fieldbus protocol support | No |
| INTERBUS protocol support | No |
| KNX protocol support | No |
| LON protocol support | No |
| MODBUS protocol support | Yes |
| PROFIBUS protocol support | No |
| PROFINET CBA protocol support | No |
| PROFINET IO protocol support | No |
| PROFIsafe protocol support | No |
| SUCONET protocol support | No |
| SafetyBUS p protocol support | No |
| TCP/IP protocol support | Yes |
| Protocol support for INTERBUS Safety | No |
| SERCOS protocol support | No |
| Protocol support for other system buses | Yes |
| Suitable for security systems | No |
| Bluetooth radio standard | No |
| GPRS radio standard | No |
| GSM radio standard | No |
| UMTS radio standard | No |
| WLAN 802.11 radio standard | No |
| Supply voltage current type | Constant (DC) |
| With display | Yes |
| With optical interface | No |
| IO-Link standard | No |
| Resistance to overloads | No |
| Width | 134 мм |
