Smooth bend 90deg vertical external (type B20) ESCA 50x200mm HDZ IEK CPV41-0-90-050-200-HDZ
SKU: CPV41-0-90-050-200-HDZ
ETIM: EC002400
2,999 ₽
Get back 29 ₽ in points
Analogues by specifications
90° vertical external smooth bend is designed for organizing a 90° vertical external bend of a cable route. The accessory cover is not included in the kit.
The accessory is made of steel with a zinc coating applied by immersion in molten zinc (zinc protective layer not less than 55 μm).
Weight
0.75 кг
Material type/grade
Galvanized steel
Internal radius
100 мм
Height
50 мм
Height
50 мм
Cable tray height
50 мм
Length
220 мм
Length
220 мм
Protective surface coating
Hot-dip coating
Direction change
Vertically descending (external)
Design
With connector
Corrosion resistance class
6
Climatic version
U1, KhL1, UKhL1, UKhL5, OM1
Material
Steel
Mounting perforation in base
No
Mounting temperature from
-50...40 град.C
Pickled stainless steel
No
RAL colour number
7047
Perforated side wall
No
Rotation (angle)
90
Suitable for circuit integrity (fire resistance)
No
IP protection rating
IP00
Operating temperature from
-50...40 град.C
Metal thickness
0.8
Zinc coating thickness
55
Colour
Light grey
Color
Light grey
Width
200 мм
Cable tray width
200 мм
Branch width
200 мм
Wide-range version
No
