ONI (Группа IEK)
Frequency converter A150 220V 1Ph 0.4kW 3A with built-in brake module ONI A150-21-04HT
SKU: A150-21-04HT
ETIM: EC001857
156,720 ₽
Get back 1,567 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 12 шт
Analogues by specifications
No description available
Input current, ND variable load mode
5
Height
152 мм
Height
152 мм
Output power at rated output voltage
0.40 кВт
Output frequency
0...600
ND mode output current at variable load
3.0
Depth
149 мм
Mechanical design group
M2
Operating input voltage range
195...264
Approved for use in residential and commercial areas
Yes
Permitted for use in industrial areas
Yes
Climatic version
UKhL3.1
Number of HW serial RS-485 interfaces
0
Number of input phases
1
Number of output phases
3
Number of phases
1
Max. motor power in ND variable load mode
0.4
Maximum output power at linear load at rated output voltage
- кВт
Maximum output frequency
600 Гц
Maximum output voltage
230 В
Control method
Open-loop vector control
Output voltage from
0...240 В
Mains voltage to
220 В
Mains voltage from
220 В
Carrier frequency
0.5...16
Rated output voltage
240 В
Rated output current
3.0 А
AS-Interface Safety at Work protocol support
No
ASI protocol support
No
CAN protocol support
No
Data Highway protocol support
No
DeviceNet protocol support
No
DeviceNet Safety protocol support
No
Ethernet / IP protocol support
No
Foundation Fieldbus protocol support
No
INTERBUS protocol support
No
KNX protocol support
No
LON protocol support
No
MODBUS protocol support
Yes
PROFIBUS protocol support
No
PROFINET CBA protocol support
No
PROFINET IO protocol support
No
PROFIsafe protocol support
No
SUCONET protocol support
No
SafetyBUS p protocol support
No
TCP/IP protocol support
No
Protocol support for INTERBUS Safety
No
SERCOS protocol support
No
Protocol support for other system buses
No
With control unit
Yes
With built-in braking resistors
Yes
With PC connection
No
IP protection rating
IP20
Operating temperature from
-10...40 град.C
Cooling type: air cooling, water cooling
Fan (built-in)
AC frequency converter type
Direct converter
Control type
V/f and open-loop vector
Mains frequency
50/60 Hz
Width
84 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
