Frequency converter FC-430 380V 3Ph 22-30kW 45-60A built-in braking module ONI FC-430-33-22G30PT

SKU: FC-430-33-22G30PT

ETIM: EC001857

172769 ₽

Available August 21

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	12	шт	August 21	August 21

Select a warehouse to order

Description Specifications Reviews

Input current HD constant load mode	46
Input current, ND variable load mode	62
Height	320 мм
Height	320 мм
Output power at rated output voltage	30 кВт
Output current, HD mode constant load	45.0
ND mode output current at variable load	60.0
Depth	184 мм
Electric shock protection class	It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Number of input phases	3
Number of output phases	3
Number of phases	3
Max. motor power in HD constant load mode	22
Max. motor power in ND variable load mode	30
Maximum output power at linear load at rated output voltage	22 кВт
Maximum output frequency	320 Гц
Maximum output voltage	400 В
Mains voltage from	380 В
Carrier frequency	0.5…16
Rated output current	60 А
MODBUS protocol support	Yes
With control unit	Yes
With built-in braking resistors	Yes
With PC connection	No
IP protection rating	IP20
Cooling type: air cooling, water cooling	Fan (built-in)
AC frequency converter type	Direct converter
Mains frequency	50/60 Hz
Width	200 мм
