Frequency converter FC-431 380V 3Ph 18.5-22kW 38-45A built-in transformer ONI FC-431-33-18G22PT
SKU: FC-431-33-18G22PT
ETIM: EC001857
306,384 ₽
Get back 3,063 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 4 шт
Analogues by specifications
Stock by warehouse
No description available
Input current HD constant load mode
38
Input current, ND variable load mode
46
Height
300 mm
Height
300 mm
Output power at rated output voltage
22.00 kW
Output current, HD mode constant load
38.0
ND mode output current at variable load
45.0
Depth
186 mm
Electric shock protection class
I
Number of input phases
3
Number of output phases
3
Number of phases
3
Max. motor power in HD constant load mode
18
Max. motor power in ND variable load mode
22
Maximum output power at linear load at rated output voltage
18 kW
Maximum output frequency
320 Hz
Maximum output voltage
400 V
Mains voltage from
380 V
Carrier frequency
0.5…16
Rated output current
45 A
MODBUS protocol support
Yes
With control unit
Yes
With built-in braking resistors
Yes
With PC connection
No
IP protection rating
IP20
Cooling type: air cooling, water cooling
Fan (built-in)
AC frequency converter type
Direct converter
Mains frequency
50/60 Hz
Width
200 mm
