Frequency converter FC-431 380V 3Ph 37-45kW 75-90A built-in braking module ONI FC-431-33-37G45PT
SKU: FC-431-33-37G45PT
ETIM: EC001857
3,195,600 ₽
Get back 31,956 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 20 шт
Analogues by specifications
Stock by warehouse
The ONI FC-431 frequency converter is designed for controlling electric drives in process control systems of medium and high complexity that do not require high regulation precision. Built-in functions allow for efficient electric drive control without the use of external ICS (Industrial Control Systems), and the built-in RS-485 interface with Modbus-RTU protocol, as well as the possibility of installing expansion boards with Profibus, Ethercat, and CANopen protocols, allow this VFD to be integrated into building automation systems of any complexity and scale.
Input current HD constant load mode
76
Input current, ND variable load mode
90
Height
390 mm
Height
390 mm
Output power at rated output voltage
45.00 kW
Output current, HD mode constant load
75.0
ND mode output current at variable load
90.0
Depth
196 mm
Electric shock protection class
I
Number of input phases
3
Number of output phases
3
Number of phases
3
Max. motor power in HD constant load mode
37
Max. motor power in ND variable load mode
45
Maximum output power at linear load at rated output voltage
37 kW
Maximum output frequency
320 Hz
Maximum output voltage
400 V
Mains voltage from
380 V
Carrier frequency
0.5…16
Rated output current
90 A
MODBUS protocol support
Yes
With control unit
Yes
With built-in braking resistors
Yes
With PC connection
No
IP protection rating
IP20
Cooling type: air cooling, water cooling
Fan (built-in)
AC frequency converter type
Direct converter
Mains frequency
50/60 Hz
Width
235 mm
