Systeme Electric
Frequency converter STV900 250kW 400V SE STV900C25N4 Systeme Electric
SKU: STV900C25N4
ETIM: EC001857
1,617,903 ₽
Get back 16,179 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
SystemeVar 900 (STV900) frequency converter. Rated power: 250 kW (G-type: overload capacity: 150% for 60s, 180% for 10s, 200% for 1s. PWM carrier frequency: 2 kHz), 280 kW (P-type: 120% for 60s. PWM carrier frequency: 2 kHz). Rated current: 480 A (G-type) / 530 A (P-type). Supply voltage 3Ph 380V (-15%) ~ 440V (+10%). IP20 protection rating. Overall dimensions (LxWxH), mm: 680x380x960. Weight: 135 kg.
Four-quadrant operation possible
Yes
Height
960 мм
Output power at rated output voltage
250 кВт
Depth
380 мм
Number of HW serial RS-485 interfaces
1
Number of analog inputs
2 шт.
Number of analogue outputs
1 шт.
Number of input phases
3
Number of output phases
3
Number of digital inputs
6 шт.
Number of digital outputs
1 шт.
Maximum output power at linear load at rated output voltage
250 кВт
Maximum output frequency
400 Гц
Maximum output voltage
440 В
Mains voltage to
400 В
Mains voltage from
400 В
Rated output voltage
400 В
Rated output current
480 А
Relative symmetrical permissible mains frequency deviation
.05 %
Relative symmetrical permissible mains voltage limit
.1 %
MODBUS protocol support
Yes
PROFIBUS protocol support
No
PROFINET IO protocol support
No
Protocol support for other system buses
No
With control unit
Yes
With optical interface
No
With PC connection
No
IP protection rating
IP20
AC frequency converter type
Converter in current source mode
Mains frequency
50/60 Hz
Width
680 мм
