Systeme Electric
Frequency converter STV900 500kW 690V SE STV900C50Y6 Systeme Electric
SKU: STV900C50Y6
ETIM: EC001857
5,017,250 ₽
Get back 50,172 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Four-quadrant operation possible
Yes
Height
1700 мм
Output power at rated output voltage
500 кВт
Depth
560 мм
Number of HW serial RS-485 interfaces
1
Number of analog inputs
2 шт.
Number of analogue outputs
1 шт.
Number of input phases
3
Number of output phases
3
Number of digital inputs
6 шт.
Number of digital outputs
1 шт.
Maximum output power at linear load at rated output voltage
500 кВт
Maximum output frequency
400 Гц
Maximum output voltage
690 В
Mains voltage to
690 В
Mains voltage from
690 В
Rated output voltage
690 В
Rated output current
540 А
Relative symmetrical permissible mains frequency deviation
.05 %
Relative symmetrical permissible mains voltage limit
.1 %
MODBUS protocol support
Yes
PROFIBUS protocol support
No
PROFINET IO protocol support
No
Protocol support for other system buses
No
With control unit
Yes
With optical interface
No
With PC connection
No
IP protection rating
IP20
AC frequency converter type
Converter in current source mode
Mains frequency
50/60 Hz
Width
620 мм
