VEDA
Frequency converter VF-101-P1K5-0004-A-T4-E20-B-H input 380V output 1.5kW output 4A overload current 4.8A built-in brake key external choke VEDA ABC00024
SKU: ABC00024
ETIM: EC001857
45,267 ₽
Get back 452 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Four-quadrant operation possible
Yes
Height
204 мм
Output power at rated output voltage
1.5 кВт
Depth
155 мм
Number of HW PROFINET interfaces
1
Number of HW USB interfaces
0
Number of HW serial RS-485 interfaces
1
Number of analog inputs
2 шт.
Number of analogue outputs
1 шт.
Number of digital inputs
5 шт.
Number of digital outputs
1 шт.
Maximum output power at linear load at rated output voltage
1.5 кВт
Maximum output voltage
480 В
Rated output voltage
380 В
Rated output current
4 А
Rated output current
4 А
Relative symmetrical permissible mains frequency deviation
3 %
Relative symmetrical permissible mains voltage limit
10 %
MODBUS protocol support
Yes
PROFIBUS protocol support
Yes
PROFINET IO protocol support
Yes
Protocol support for other system buses
Yes
With control unit
Yes
With optical interface
No
With PC connection
Yes
IP protection rating
IP20
AC frequency converter type
Converter in voltage source mode
Width
80 мм
