Frequency converter VF-101-P37K-0075-A-T4-E20-N-H input 380V output 37kW output 75A overload current 90A external braking resistor external reactor VEDA ABC00034
SKU: ABC00034
ETIM: EC001857
274,743 ₽
Get back 2,747 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Four-quadrant operation possible
Yes
Height
433.5 мм
Output power at rated output voltage
37 кВт
Depth
225 мм
Number of HW PROFINET interfaces
1
Number of HW USB interfaces
0
Number of HW serial RS-485 interfaces
1
Number of analog inputs
2 шт.
Number of analogue outputs
1 шт.
Number of digital inputs
5 шт.
Number of digital outputs
1 шт.
Maximum output power at linear load at rated output voltage
37 кВт
Maximum output voltage
480 В
Rated output voltage
380 В
Rated output current
75 А
Rated output current
75 А
Relative symmetrical permissible mains frequency deviation
3 %
Relative symmetrical permissible mains voltage limit
10 %
MODBUS protocol support
Yes
PROFIBUS protocol support
Yes
PROFINET IO protocol support
Yes
Protocol support for other system buses
Yes
With control unit
Yes
With optical interface
No
With PC connection
Yes
IP protection rating
IP20
AC frequency converter type
Converter in voltage source mode
Width
172 мм
