VEDA
Frequency converter VF-51-P15K-0032-T4-E20-B-H input 380V output 15kW output 32A VEDA ABA00012
SKU: ABA00012
ETIM: EC001857
102,395 ₽
Get back 1,023 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Four-quadrant operation possible
Yes
Height
342.5 мм
Output power at rated output voltage
15 кВт
Depth
183 мм
Number of HW PROFINET interfaces
0
Number of HW USB interfaces
0
Number of HW serial RS-485 interfaces
1
Number of analog inputs
1 шт.
Number of analogue outputs
1 шт.
Number of digital inputs
1 шт.
Number of digital outputs
4 шт.
Maximum output power at linear load at rated output voltage
15 кВт
Maximum output voltage
480 В
Rated output current
32 А
Rated output current
32 А
MODBUS protocol support
Yes
PROFIBUS protocol support
No
PROFINET IO protocol support
No
Protocol support for other system buses
No
With optical interface
No
With PC connection
Yes
IP protection rating
IP20
AC frequency converter type
Converter in voltage source mode
Width
170 мм
