IEK
Auxiliary Contact Block PKI-20 additional contacts 2NO IEK KPK10-20
SKU: KPK10-20
ETIM: EC001043
72,895 ₽
Get back 728 ₽ in points
Order multiple: 250 шт
Analogues by specifications
Stock by warehouse
PKI contact attachments are designed to expand the capabilities of contactors in automation systems for technological projects.
Weight
0.03 кг
Height
47.0 мм
Depth
38.0 мм
Operating temperature range
-40...+50
Climatic version
UKhL4
Number of normally closed (NC) contacts
0
Number of normally open (NO) contacts
2
Max. short-time load
100.0
Maximum conductor cross-section
2x2.5 кв.мм
Mech. endurance
1.6x10^6
Min making capacity at min voltage
24.0
Min. making capacity at min. current
10.0
Rated DC operating current DC-13 400 V
0.63
Rated operating current Ie at AC-15 400 V
3.00
Rated operating current Ie at AC-15 660 V
1.50
Rated insulation voltage Ui
690 В
Rated control supply voltage Us AC at 50 Hz from
660/400/230 В
Rated control supply voltage Us DC up to
400 В
Rated control supply voltage Us DC from
400/220 В
Rated operational current Ie at AC-15, 230V
6.0 А
Rated operating current Ie at DC-13, 230 V
1.5 А
Repairability
No
Switch-on current type
AC/DC
With built-in protection
No
Insulation resistance
10.0
IP protection rating
IP20
Installation type
Direct mounting
Contactor design
All KMI, KTI versions
Thermal resistance current
10.0
Width
25.0 мм
