DKC
Feed-through terminal 2 connection points 4 sq.mm blue (replaced by VPR-4-BU) ZEFC400BL DKC
SKU: ZEFC400BL
ETIM: EC000897
56 ₽
Price list (incl. VAT):
79 ₽
Preorder
No description available
| Version tested for explosion protection "Ex e" | Yes |
| Internally linked levels | Yes |
| Minimum possible mounting height | 39.2 мм |
| Length | 55.2 мм |
| Length | 55.2 мм |
| Flammability class of insulation material in accordance with UL57 | EV004429 |
| Number of terminals per level | 2 |
| Number of poles | 2 |
| Number of levels | 1 |
| Housing insulation material | EV000403 |
| Rated voltage | 800 В |
| Rated current In | 32 А |
| Closing plate can be fitted if required | Yes |
| Operating temperature from | -60...130 град.C |
| Connection position | EV000644 |
| Stranded wire cross-section with ferrule | 4...4 мм² |
| Stranded flexible conductor cross-section from | 0.2...4 кв.мм |
| Solid conductor cross-section from | 0.2...6 кв.мм |
| Extra-fine-stranded flexible conductor cross-section without ferrule, from | 0.2...4 кв.мм |
| Mounting method | EV005503 |
| Electrical connection type 1 | EV005752 |
| Electrical connection type 2 | EV005752 |
| Colour | Blue |
| Color | EV000080 |
| Width/connection pitch | 6.2 мм |
