DKC
Feed-through terminal 3 connection points for 4 mm² (replacement for VPR-4-TWIN-GY) ZEFC410GR DKC
SKU: ZEFC410GR
ETIM: EC000897
72 ₽
Get back 1% in points
Analogues by specifications
Stock by warehouse
No description available
Version tested for explosion protection "Ex e"
Yes
Internally linked levels
Yes
Minimum possible mounting height
39.2 мм
Length
71.8 мм
Length
71.8 мм
Flammability class of insulation material in accordance with UL57
EV004429
Number of terminals per level
3
Number of poles
3
Number of levels
1
Housing insulation material
EV000403
Rated voltage
800 В
Rated current In
32 А
Closing plate can be fitted if required
Yes
Operating temperature from
-60...130 град.C
Connection position
EV000644
Stranded wire cross-section with ferrule
0.2...4 мм²
Stranded flexible conductor cross-section from
0.2...4 кв.мм
Solid conductor cross-section from
0.2...6 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...4 кв.мм
Mounting method
EV005503
Electrical connection type 1
EV005752
Electrical connection type 2
EV005752
Colour
Grey
Color
EV000270
Width/connection pitch
6.2 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
