Wire PuGV 1x25 450/750V C (m) ELEKTROKABEL NN 00-00007430
SKU: 00-00007430
ETIM: EC000993
381 ₽
Preorder
PuGV 25 G (m) ElektrokabelNN M0001181 – flexible installation wire with a copper conductor cross-section of 25 sq.mm.
With PVC insulation, without an outer sheath, blue color.
Sensitive to UV radiation and precipitation. Used in dry rooms, under a covered canopy.
Designed for use in lighting and power networks, when connecting electrical equipment 450/750 V.
| Conductor diameter | 6.69 мм |
| Permissible operating temperature (no movement) to | 65 град.C |
| Permissible operating temperature (without movement) from | -40 град.C |
| Core insulation | Polyvinyl chloride (PVC) |
| Conductor class | 5 - flexible stranded |
| Cable/wire grade | PuGV (PV3) |
| Oil resistance in accordance with EN 60811-2-1 | No |
| Display present | No |
| Outer diameter (approx.) | 9.09 мм |
| Low smoke emission in accordance with EN 61034-2 (ng-LS version) | No |
| Fire resistance | No |
| Recommended installation temperature during pulling, up to | 40 град.C |
| Recommended installation temperature during pulling from | 15 град.C |
| Core cross-section | 25 мм |
| Low temperature resistance in accordance with EN 60811-1-4 | Yes |
| Wire color | Blue |
