Wire PuVng(A)-LS 1x25 MK 450/750V white (m) ELEKTROKABEL NN 00-00005519
SKU: 00-00005519
ETIM: EC000993
427 ₽
Price list (incl. VAT):
427 ₽
Available August 3
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Remote warehouse
Available
|
350 | м | August 3 | August 3 |
Select a warehouse to order
Bare wire with copper core with insulation and sheath made of low-fire-hazard polyvinyl chloride plastisol is used for electrical installations during stationary installation in lighting networks, installation in steel pipes, conduits, as well as for mounting electrical equipment, machines, mechanisms and tools at a nominal alternating voltage up to 450/750 V inclusive, frequency up to 400 Hz or direct voltage up to 1000 V inclusive.
| Conductor diameter | 6.42 мм |
| Permissible operating temperature (no movement) to | 65 град.C |
| Permissible operating temperature (without movement) from | -40 град.C |
| Core insulation | Polyvinyl chloride (PVC) |
| Conductor class | 2 - stranded |
| Cable/wire grade | PuVng(A)-LS |
| Oil resistance in accordance with EN 60811-2-1 | No |
| Display present | No |
| Outer diameter (approx.) | 8.62 мм |
| Low smoke emission in accordance with EN 61034-2 (ng-LS version) | Yes |
| Fire resistance | No |
| Recommended installation temperature during pulling, up to | 40 град.C |
| Recommended installation temperature during pulling from | 15 град.C |
| Core cross-section | 25 мм |
| Low temperature resistance in accordance with EN 60811-1-4 | Yes |
| Wire color | White |
