Wire TOKOV ELECTRIC PuGVng(A)-LS 1x240 yellow-green 450/750V (m) UT000032042 TOKOV ELECTRIC KPP
SKU: УТ000032042
ETIM: EC000993
4010 ₽
Price list (incl. VAT):
3963 ₽
Available August 7
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Transit warehouse
Available
|
353 | м | August 7 | clarifying |
Select a warehouse to order
Installation wires are intended for electrical installations during stationary laying in lighting networks, as well as for mounting electrical equipment of machines, mechanisms, and tools at a rated alternating voltage of 450/750 V, frequency up to 400 Hz, or direct current up to 1000 V inclusive.
Description: the conductor is copper, round-shaped, multi-stranded. The design of the conductor corresponds to class 5 according to GOST 22483. The insulation of the conductor is made of PVC plastisol. Possible color options: black, brown, red, blue, white, yellow-green.
Operating temperature: from minus 40°C to plus 65°C
Installation temperature: not lower than minus 15°C
PuGVng(A)-LS wires do not propagate combustion during group laying. Fire hazard class: P1b.8.2.2.2 according to GOST 31565-2012
| Permissible operating temperature (no movement) to | 65 град.C |
| Permissible operating temperature (without movement) from | -40 град.C |
| Core insulation | Polyvinyl chloride (PVC) |
| Conductor class | 5 - flexible stranded |
| Cable/wire grade | PuGVng(A)-LS |
| Oil resistance in accordance with EN 60811-2-1 | No |
| Display present | No |
| Low smoke emission in accordance with EN 61034-2 (ng-LS version) | Yes |
| Rated voltage U | 450 кВ |
| Fire resistance | No |
| Recommended installation temperature during pulling, up to | -15 град.C |
| Recommended installation temperature during pulling from | -15 град.C |
| Core cross-section | 240 мм |
| Low temperature resistance in accordance with EN 60811-1-4 | No |
| Wire color | Yellow-green |
