High-power floodlight with a wide range of power ratings and optics. Best lumen/weight/size ratio in its class of solutions.
Cast aluminum heatsink, steel enclosure parts, acrylic secondary optics.
For lighting sports facilities, large spaces, and high-mast lighting. Mounting on a flat surface using a swivel bracket. The mounting bracket has a 30° tilt to the horizontal for comfortable aiming of the floodlight when lighting sports facilities. Rotation angle from 30° to 165° with a 5° step.
| Without dimming | No |
| Supplied with lamp | Yes |
| Height/depth | 387 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | No |
| DMX dimming | Yes |
| Voltage modulation dimming | No |
| Length | 524 мм |
| Protective surface coating | Powder-coated |
| Colour rendering index | 80-89 (class 1B) |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Number of poles | 5 |
| Power factor | .95 |
| Maximum power | 280 Вт |
| Housing material | Aluminum |
| Diffuser/lampshade material | Transparent plastic |
| Matt surface | No |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 39500 лм |
| Rated LED DC current from | 656 мА |
| Colour uniformity (MacAdam ellipse) | SDCM5 |
| Reflector | No (without) |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | No |
| Suitable for number of light sources | 1 |
| Suitable for low-voltage busbar trunking | No |
| Designed for flush mounting | No |
| Programmable dimming | No |
| Current type | AC/DC |
| With motion sensor | No |
| With light sensor | No |
| Light output | Straight |
| Luminous flux from | 39500 лм |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | .75 кв.мм |
| Connectable conductor cross-section at | 4 кв.мм |
| Connected conductor cross-section from | 1 кв.мм |
| Mounting method | Surface mounting |
| IP protection rating | IP67 |
| Ambient temperature up to | 40 град.C |
| Ambient temperature from | -40 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Medium beam 20-40 deg. |
| Impact resistance | IK01 |
| Control device | LED current-controlled device |
| Housing color | Grey |
| Light color | White |
| Colour temperature from | 4000 К |
| Lamp base (holder) | No (without) |
| Width | 336 мм |
| Luminaire efficiency | 141 лм/Вт |
