Varton
AirQub Sport TV LED floodlight 850W 5700K 30deg. DALI dimmer VARTON V1-P0-703X4-04D02-6585057
SKU: V1-P0-703X4-04D02-6585057
ETIM: EC001744
Price on request
Analogues by specifications
Modular design, wide range of power and optical solutions for the ideal balance of weight, wind load, and illumination. Die-cast aluminum radiator, steel housing parts, acrylic (PMMA) secondary optics. The mounting bracket has a 30° horizontal tilt for convenient aiming of the floodlight when illuminating sports facilities. SPORT TV version - highest light quality, for sports facilities with television broadcasts. Mounting: surface-mounted using a swivel yoke. Tilt angle adjustment from 30° to 165° with 5° increments. Convenience of connection to the power supply and control via the built-in junction box on the housing.
Without dimming
No
Supplied with lamp
Yes
Height/depth
636 мм
0-10 V dimming
No
1-10V dimming
No
DALI dimming
Yes
DMX dimming
No
Voltage modulation dimming
No
Length
581 мм
Protective surface coating
Powder-coated
Colour rendering index
90-100 (class 1A)
Electric shock protection class
I
Number of poles
5
Power factor
.95
Maximum power
850 Вт
Housing material
Aluminum
Diffuser/lampshade material
Transparent plastic
Matt surface
No
Rated voltage up to
230 В
Rated voltage from
220 В
Rated luminous flux
94500 лм
Rated LED DC current from
664 мА
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
No
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
No
Programmable dimming
No
Current type
AC/DC
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
94500 лм
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
.75 кв.мм
Connectable conductor cross-section at
4 кв.мм
Connected conductor cross-section from
1 кв.мм
Mounting method
Surface mounting
IP protection rating
IP67
Ambient temperature up to
40 град.C
Ambient temperature from
-40 град.C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Medium beam 20-40 deg.
Impact resistance
IK01
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Colour temperature from
5700 К
Lamp base (holder)
No (without)
Width
676 мм
Luminaire efficiency
111 лм/Вт
