Varton
LED floodlight FL-Pro ASWM 200W 5000K RAL7045 moiré series VARTON V1-I0-70591-04L51-6520050
SKU: V1-I0-70591-04L51-6520050
ETIM: EC001744
Price on request
Analogues by specifications
Floodlights with high luminous efficacy and a wide selection of optical solutions. The power source, LED module, and optics are located in a die-cast aluminum housing and are protected by impact-resistant tempered glass. Installation: surface-mounted, using a swivel yoke on a horizontal or vertical supporting surface, position adjustment in the range of 0-180 degrees. Applicable for lighting industrial enterprises and warehouse complexes, hazardous zones (P-I, II, IIa, III), entrance groups, open spaces, and architectural lighting.
Without dimming
Yes
Supplied with lamp
Yes
Height/depth
95 мм
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
507 мм
Protective surface coating
Powder-coated
Colour rendering index
70-79 (class 2A)
Electric shock protection class
I
Number of poles
3
Power factor
.95
Maximum power
200 Вт
Housing material
Aluminum
Diffuser/lampshade material
Clear glass
Matt surface
No
Rated voltage up to
230 В
Rated voltage from
220 В
Rated luminous flux
27200 лм
Rated LED DC current from
469 мА
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
No
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
No
Programmable dimming
No
Current type
AC/DC
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
27200 лм
Light distribution
Asymmetric
Touch dimming
No
Core cross-section
1 кв.мм
Connected conductor cross-section from
1 кв.мм
Mounting method
Surface mounting
Connection method
Clamp contact
IP protection rating
IP66
Ambient temperature up to
45 град.C
Ambient temperature from
-40 град.C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Wide beam 41-80 deg
Impact resistance
IK08
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Colour temperature from
5000 К
Lamp base (holder)
No (without)
Width
339 мм
Luminaire efficiency
136 лм/Вт
