Electromagnetic starter PM12-125100 230V 2NC+4NO EKF Basic pm12-125/220
SKU: pm12-125/220
ETIM: EC000066
13,404 ₽
Get back 134 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
PM12 series electromagnetic contactors are intended for use in AC circuits with voltage up to 660V at frequencies of 50 and 60 Hz for remote starting and stopping of electric motors. PM12 Basic series electromagnetic contactors comply with GOST IEC 60947-4-1-2021.
Number of auxiliary NO contacts
2
Number of auxiliary break contacts
4
Number of main NO contacts
3
Number of main NC contacts
0
Modular design
No
Rated switching power at AC-4, 400 V
21 кВт
Rated operational current Ie at AC-4, 400 V
46 А
Rated power at AC-3, 400 V
55 кВт
Rated operational power (NEMA)
35 кВт
Rated control supply voltage Us AC at 50 Hz up to
253 В
Rated control supply voltage Us AC at 50 Hz from
195.5...253 В
Rated control supply voltage Us DC up to
0 В
Rated control supply voltage Us DC from
0 В
Rated operational current Ie at AC-1, 400 V
125 А
Rated operating current Ie at AC-3, 400 V
125 А
Switch-on current type
AC (alternating)
Main electrical circuit connection type
Screw connection
