Electromagnetic starter PM12-800100 230V 2NC+4NO EKF Basic pm12-800/220
SKU: pm12-800/220
ETIM: EC000066
68047 ₽
Price list (incl. VAT):
127589 ₽
Preorder
PM12 series electromagnetic contactors are intended for use in AC circuits with voltage up to 660V at frequencies of 50 and 60 Hz for remote starting and stopping of electric motors. PM12 Basic series electromagnetic contactors comply with GOST IEC 60947-4-1-2021.
| Number of auxiliary NO contacts | 2 |
| Number of auxiliary break contacts | 2 |
| Number of main NO contacts | 3 |
| Number of main NC contacts | 0 |
| Modular design | No |
| Rated switching power at AC-4, 400 V | 167 кВт |
| Rated operational current Ie at AC-4, 400 V | 296 А |
| Rated power at AC-3, 400 V | 450 кВт |
| Rated operational power (NEMA) | 220 кВт |
| Rated control supply voltage Us AC at 50 Hz up to | 253 В |
| Rated control supply voltage Us AC at 50 Hz from | 195.5...253 В |
| Rated control supply voltage Us DC up to | 0 В |
| Rated control supply voltage Us DC from | 0 В |
| Rated operational current Ie at AC-1, 400 V | 800 А |
| Rated operating current Ie at AC-3, 400 V | 800 А |
| Switch-on current type | AC (alternating) |
| Main electrical circuit connection type | Screw connection |
