Phase control relay OptiRel D PHS-3-1M-03-PN-1 phase sequence and phase loss 3F+N 1CO KEAZ 331983
SKU: 331983
ETIM: EC001441
1,839 ₽
Get back 18 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Modular phase control relays are designed to protect electrical equipment and consumers in case of power supply network quality violations. They perform continuous voltage monitoring in single-phase and three-phase AC networks, disconnecting equipment with a specified time delay when voltage goes outside the range, as well as monitoring the correct phase sequence, loss of one or more phases, and the neutral.
Depth
64 мм
Voltage measuring range to
318 В
Voltage measuring range from
101 В
Number of normally closed (NC) contacts
0
Number of normally open (NO) contacts
0
Number of switching contacts
1
Maximum permissible delay time
10 с
Maximum permissible trip delay time without holding
.5 с
Minimum adjustable delay time
10 с
Minimum adjustable response delay time without time lag
.5 с
Rated control supply voltage Us AC at 50 Hz up to
265 В
Rated control supply voltage Us AC at 50 Hz from
127 В
Rated control supply voltage Us DC up to
0 В
Rated control supply voltage Us DC from
0 В
Switch-on current type
Alternating current (AC)
Phase sequence monitoring function
Yes
Phase asymmetry detection function
Yes
Phase failure detection function
Yes
Overvoltage detection function
No
Undervoltage detection function
No
Width
18 мм
