![Voltage monitoring relay 3ph EL-12M-15 UKHL4 AC 100V [spec.] trip delay 0.1...10s contact current 8A 2p Meandr A8302-16934386](/uploads/meandr/a8302-16934386/a8302-16934386-1.webp)
Меандр
Voltage monitoring relay 3ph EL-12M-15 UKHL4 AC 100V [spec.] trip delay 0.1...10s contact current 8A 2p Meandr A8302-16934386
SKU: A8302-16934386
ETIM: EC001438
3,058 ₽
Get back 30 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
1-phase undervoltage monitoring possible
Yes
3-phase undervoltage monitoring possible
Yes
Height
93 мм
Depth
62 мм
Voltage measurement range 1 at
125 В
Voltage measurement range 1 from
75 В
Voltage measuring range 2 to
130 В
Voltage measuring range 2 from
50 В
Number of normally closed (NC) contacts
0
Number of normally open (NO) contacts
0
Number of switching contacts
2
Maximum permissible delay time
10 с
Maximum permissible trip delay time without holding
.1 с
Minimum adjustable delay time
.1 с
Rated control supply voltage Us AC at 50 Hz up to
150 В
Rated control supply voltage Us AC at 50 Hz from
50 В
Tripping threshold voltage to
130 В
Response threshold voltage from
50 В
Switch-on current type
Alternating current (AC)
Monitored voltage current type
Alternating current (AC)
With removable terminals, clamps
No
Includes DC voltage monitoring functions - hysteresis
No
Includes DC voltage monitoring functions - overvoltage
No
Includes DC voltage monitoring functions - undervoltage
No
Width
18 мм
