Single-phase voltage monitoring relay, type DRV, contact configuration 1CO, 110-240V AC/DC DRV-C-1-240ACDC DKC

SKU: DRV-C-1-240ACDC

ETIM: EC001438

3891 ₽

Price list (incl. VAT): 3269 ₽

Available August 3

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Смоленск
	Склад производителя Available	994	шт	August 3	August 3

Select a warehouse to order

Description Specifications Reviews

1-phase	true
3-phase	false
1-phase hysteresis monitoring possible	true
1-phase undervoltage monitoring possible	Yes
3-phase hysteresis monitoring possible	false
3-phase undervoltage monitoring possible	No
Height	90 мм
Height	90 мм
Depth	65 мм
Voltage measurement range 1 at	260 В
Voltage measurement range 1 from	65 В
Voltage measuring range 2 to	260 В
Voltage measuring range 2 from	65 В
Number of normally closed (NC) contacts	1
Number of normally open (NO) contacts	1
Number of switching contacts	1
Maximum permissible delay time	10 с
Minimum adjustable delay time	.1 с
Rated control supply voltage Us AC at 50 Hz up to	240 В
Rated control supply voltage Us AC at 50 Hz from	110 В
Rated control supply voltage Us DC up to	240 В
Rated control supply voltage Us DC from	110 В
Switch-on current type	AC/DC
Monitored voltage current type	AC/DC
With removable terminals, clamps	No
Includes DC voltage monitoring functions - hysteresis	Yes
Includes DC voltage monitoring functions - overvoltage	Yes
Includes DC voltage monitoring functions - undervoltage	Yes
Connection type	Screw connection
Width	18 мм
