IEK
Voltage and current relay RNT-d single-phase 36mm 63A IEK IVC21-1-63
SKU: IVC21-1-63
ETIM: EC001438
3,534 ₽
Get back 35 ₽ in points
Analogues by specifications
Stock by warehouse
No description available
1-phase
Yes
3-phase
No
1-phase hysteresis monitoring possible
Yes
1-phase undervoltage monitoring possible
Yes
3-phase hysteresis monitoring possible
No
3-phase undervoltage monitoring possible
No
Time delay
5...600
Height
90 мм
Height
90 мм
Hysteresis
2
Depth
66 мм
Voltage measurement range 1 at
210 В
Voltage measurement range 1 from
140...210 В
Voltage measuring range 2 to
280 В
Voltage measuring range 2 from
220...280 В
Supply voltage frequency range
50/60
Voltage presence indicator
Green LED (Un)
Relay tripping indicator
Red LED (R)
Number of normally open (NO) contacts
1
Number of switching contacts
0
Number of changeover contacts
0
Max. cross-section of stranded cable with ferrules
16
Max. single-core cable cross-section
16
Maximum permissible trip delay time without holding
600 с
Mech. endurance
100000
Minimum adjustable response delay time without time lag
5.0 с
Rated voltage of contact assembly
220
Rated current of contact groups at AC-1
63
Rated voltage
220 В
Rated control supply voltage Us AC at 50 Hz from
220 В
Rated control circuit AC supply voltage Us at 60 Hz from
220 В
Rated control supply voltage Us DC from
Please provide the text you would like me to translate. В
Measurement error
2
Repairability
No
Switch-on current type
Alternating current (AC)
Monitored voltage current type
Alternating current (AC)
With removable terminals, clamps
No
Includes DC voltage monitoring functions - hysteresis
No
Includes DC voltage monitoring functions - overvoltage
No
Includes DC voltage monitoring functions - undervoltage
No
Mounting method
DIN rail (standard) 35 mm
Pollution degree
3
IP protection rating of terminal
IP00
Ingress protection (IP) of front panel
IP20
Operating temperature from
-20...+55 град.C
Connection type
Screw connection
Width
37 мм
Electrical endurance
5000
