Voltage relay (through connection) RVb-40A EKF Basic rvb-40a
SKU: rvb-40a
ETIM: EC001438
2214 ₽
Price list (incl. VAT):
2161 ₽
Preorder
EKF PROxima voltage and current relay is a microprocessor device designed for continuous voltage monitoring in single-phase and three-phase (MRVA-3) AC networks, to protect electrical installations from voltage surges. The relay monitors the network voltage within a set range and, if the voltage goes outside the range, disconnects the equipment from the power supply with a specified time delay. Setting the voltage range and response time is done using rotary regulators (RV-5A, RV-32F) or using buttons (MRV, MRVA, MRVs) located on the front surface of the relay.
| 1-phase | Yes |
| 3-phase | No |
| 1-phase hysteresis monitoring possible | Yes |
| 1-phase undervoltage monitoring possible | Yes |
| 3-phase hysteresis monitoring possible | No |
| 3-phase undervoltage monitoring possible | No |
| Height | 90 мм |
| Height | 90 мм |
| Depth | 60 мм |
| Voltage measurement range 1 at | 175 В |
| Voltage measurement range 1 from | 165...175 В |
| Voltage measuring range 2 to | 275 В |
| Voltage measuring range 2 from | 260...275 В |
| Number of normally closed (NC) contacts | 0 |
| Number of normally open (NO) contacts | 1 |
| Number of switching contacts | 0 |
| Maximum permissible delay time | 2 с |
| Maximum permissible trip delay time without holding | 35 с |
| Minimum adjustable delay time | 1.5 с |
| Minimum adjustable response delay time without time lag | 25 с |
| Rated control supply voltage Us AC at 50 Hz up to | 300 В |
| Rated control supply voltage Us AC at 50 Hz from | 60...300 В |
| Rated control circuit AC supply voltage Us at 60 Hz from | 60...300 В |
| Rated control supply voltage Us DC up to | 0 В |
| Rated control supply voltage Us DC from | 0 В |
| Rated switching current | 40 А |
| Tripping threshold voltage to | 275 В |
| Response threshold voltage from | 165...275 В |
| Switch-on current type | AC (alternating) |
| Monitored voltage current type | AC (alternating) |
| With removable terminals, clamps | No |
| Includes DC voltage monitoring functions - hysteresis | No |
| Includes DC voltage monitoring functions - overvoltage | No |
| Includes DC voltage monitoring functions - undervoltage | No |
| Connection type | Screw connection |
| Width | 53.5 мм |
