DEKraft
Intermediate relay PR-102 5A 24V DC 2 cont. with LED indication and TEST func. DEKraft 23839DEK
SKU: 23839DEK
ETIM: EC001437
461 ₽
Get back 4 ₽ in points
Analogues by specifications
Stock by warehouse
Intermediate relay PR-102 Dekraft series; rated current 5 A; rated coil voltage 24 V DC; number of contacts - 2 changeover; installation - on DIN rail or mounting panel. The design includes a TEST button to check the functionality of the contact group. PR-102 intermediate relays are designed to control low-power loads requiring frequent switching. An LED indicator shows the relay status. The relay has compact dimensions, allowing it to be used in areas with limited installation space.
Supplied with socket
No
Type of changeover contacts
Single contact
Height
27.5 мм
Depth
35.5 мм
Number of normally closed (NC) contacts
0
Number of normally open (NO) contacts
0
Number of switching contacts
2
Rated control supply voltage Us DC up to
24 В
Rated control supply voltage Us DC from
24 В
Rated operational current Ie, 400 V
5 А
Rated current
5 А
Polarization
Defined polarity
Switch-on current type
Direct current (DC)
With LED display
Yes
With removable terminals, clamps
No
IP protection rating
IP21
Connection type
Plug connector
Switching characteristics
Monostable
Width
21.5 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
